0.5-litre fanless PC with Android supports HDMI 2.0 and PoE
The Shuttle XPC nano NS02EV2 is one of the most affordable models Shuttle’s product family of Mini PCs has on offer. It not only convinces by its stunning looks and reliable long-term performance alone, it also comes with an integrated Octa-Core ARM processor and pre-installed Android operating system. Featuring HDMI 2.0, 4x USB 2.0, Gigabit-LAN, WLAN-ac and a built-in card reader, they easily connect to diverse peripheral devices for different kinds of application. The NS02EV2 version includes Power-over-Ethernet (PoE). This product is particularly intended for digital signage and Thin Client applications.
Shuttle NS02EV2 XPC Nano Barebone PC, Rockchip, RK3368, 2 GB, DDR3L-SDRAM, 16 GB, Android 8.1
€101,99 incl. BTW
GTIN: 0887993601540
Categorie: Computers
Sub categorie: Barebone
Beschikbaar via nabestelling
Additional information
| Merk | Shuttle |
|---|---|
| GTIN | 0887993601540 |
| Fabrikant code | NS02EV2 |
| Fabrikant link | https://www.shuttle.eu/en/products/nano/ns02ev2 |
| Artikelnummer | 1060923 |
| Thuiskopieheffing |
Processorfabrikant | Rockchip |
|---|---|
Processorfamilie | Rockchip |
Processormodel | RK3368 |
Aantal processorkernen | 8 |
Maximale turbofrequentie van processor | 1,5 GHz |
Intern geheugen | 2 GB |
|---|---|
Maximum intern geheugen | 2 GB |
Intern geheugentype | DDR3L-SDRAM |
Totale opslagcapaciteit | 16 GB |
|---|---|
Opslagmedia | eMMC |
Soort optische drive | ✕ |
Geïntegreerde geheugenkaartlezer | ✓ |
Compatibele geheugenkaarten | SD, SDHC, SDXC |
Aparte grafische adapter | ✕ |
|---|---|
Ingebouwde grafische adapter | ✓ |
Discreet grafische adapter model | Niet beschikbaar |
On-board graphics adapter model | PowerVR SGX6110 |
Videokaart, ondersteuning Open GL | ✓ |
Ethernet LAN | ✓ |
|---|---|
Ethernet LAN, data-overdrachtsnelheden | 10,100,1000 Mbit/s |
Bekabelingstechnologie | 10/100/1000Base-T(X) |
LAN controller | Realtek RTL8211F-CG |
Wifi | ✓ |
Wifi-standaard | Wi-Fi 5 (802.11ac) |
Wi-Fi-standaarden | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
Bluetooth | ✓ |
Bluetooth-versie | 5.0 |
Wake-on-LAN | ✓ |
Aantal USB 2.0-poorten | 4 |
|---|---|
Aantal HDMI-poorten | 1 |
HDMI versie | 2.0 |
Aantal Ethernet LAN (RJ-45)-poorten | 1 |
Lijnuitgang | ✓ |
Aansluiting voor netstroomadapter | ✓ |
Type behuizing | Nettop |
|---|---|
Volume | 0,577 l |
VESA-montage | ✓ |
Bevestigingsmogelijkheid voor kabelslot | ✓ |
Kabelslot sleuf type | Kensington |
Kleur van het product | Zwart |
Materiaal behuizing | Kunststof |
Audiochip | Realtek ALC5640-VB |
|---|---|
Wachtwoordbeveiliging | ✓ |
Type product | Mini PC |
Inclusief besturingssysteem | Android 8.1 |
|---|
Netvoeding | 24 W |
|---|---|
Voeding, voltage ingang | 100 - 240 V |
Ingangsfrequentie voeding | 50 - 60 Hz |
Bedrijfstemperatuur (T-T) | 0 - 40 °C |
|---|---|
Relatieve vochtigheid in bedrijf (V-V) | 10 - 90 procent |
Certificaten van naleving | RoHS |
|---|---|
Certificering | CE, FCC, BSMI, RCM, VCCI |
Duurzaamheidscertificaten | ErP |
|---|
Breedte | 141 mm |
|---|---|
Diepte | 141 mm |
Hoogte | 29 mm |
Gewicht | 270 g |
Gewicht verpakking | 650 g |
|---|
Inclusief VESA-montage | ✓ |
|---|
Code geharmoniseerd systeem (HS) | 84715000 |
|---|
Inclusief monitor | ✕ |
|---|
