The GEP-2821 is LevelOne latest generation of 28-Port Gigabit Unmanaged PoE Switch, with 2 Gigabit RJ45 and 2 Gigabit SFP Uplink ports. also offers powerful DIP switch button configuration for VLAN mode and Default mode features. Switch that gives you a high-performance, low-cost, easy-to-use, seamless upgrade to boost your network to 1000Mbps. Increase the speed of your network backbone to a massive 56Gbps and bring Gigabit speeds all the way to your computers.
The GEP-2821 PoE-enabled switches features an IEEE 802.3af/at certified, better PoE functionality with 390W PoE power budget and usability. supports up to 24 ports at 15.4W, or 13 ports at 30 W to meet the increasing power demands of users. giving you flexibility in power allocation for a variety of powered devices enabling you to scale your operations to meet business growth, operational cost savings, and ease of management.
LevelOne GEP-2821 GEP-2821, Unmanaged, Gigabit Ethernet (10/100/1000), PoE, Rack mount, 1U
€328,99 incl. BTW
GTIN: 4015867223901
Categorie: Netwerk producten
Sub categorie: Switches & hubs
1 op voorraad (kan nabesteld worden)
Additional information
| Merk | LevelOne |
|---|---|
| GTIN | 4015867223901 |
| Fabrikant code | GEP-2821 |
| Fabrikant link | https://www.level1.com/ |
| Artikelnummer | 1061212 |
| Thuiskopieheffing |
Switch type | Unmanaged |
|---|
Aantal basis-switching RJ-45 Ethernet-poorten | 28 |
|---|---|
Type basis-switching RJ-45 Ethernet-poorten | Gigabit Ethernet (10/100/1000) |
Fast Ethernet (koperen) ports kwantiteit | 24 |
Aantal Gigabit Ethernet (koper)-poorten | 2 |
Aantal moduleslots SPF | 2 |
Netwerkstandaard | IEEE 802.1af, IEEE 802.3at |
|---|---|
10G support | ✕ |
VLAN=ondersteuning | ✓ |
Transmissie afstand (max) | 0,25 km |
|---|
MAC-adrestabel | 8000 entries |
|---|---|
Packet buffergeheugen | 42 MB |
Rack-montage | ✓ |
|---|---|
Stapelbaar | ✓ |
Vormfactor | 1U |
Kleur van het product | Zwart |
LED-indicatoren | ✓ |
Type processor | ✓ |
|---|---|
Processormodel | Realtek RTL8382L |
Flash memory | 4 MB |
MTBF (PoE) | 290000 uur |
AC-ingangsspanning | 100 - 240 V |
|---|---|
AC-ingangsfrequentie | 50 - 60 Hz |
Spanningsbeveiliging | ✓ |
Overspanningsbeveiliging in voltage | 6 kV |
Power over Ethernet (PoE) | ✓ |
|---|---|
Hoeveelheid Power over Ethernet (PoE) ports | 30 |
Vermogen per poort Power over Ethernet (PoE) | 15,4 W |
Totaal Power over Ethernet (PoE)-budget | 390 W |
Bedrijfstemperatuur (T-T) | -10 - 85 °C |
|---|---|
Temperatuur bij opslag | -40 - 90 °C |
Relatieve vochtigheid in bedrijf (V-V) | 0 - 90 procent |
Warmtedissipatie | 119,544 BTU/h |
Breedte | 285 mm |
|---|---|
Diepte | 442 mm |
Hoogte | 44 mm |
Gewicht | 4 kg |
Meegeleverde kabels | AC |
|---|---|
Snelstartgids | ✓ |
Rekbevestigingspakket | ✓ |
Type verpakking | Doos |
|---|---|
Breedte verpakking | 395 mm |
Diepte verpakking | 90 mm |
Hoogte verpakking | 530 mm |
Gewicht verpakking | 4,8 kg |
Pallet nettohoogte | 140,4 cm |
|---|---|
Pallet nettodiepte | 80 cm |
Pallet nettobreedte | 120 cm |
Certificering | CE, RoHS |
|---|
Land van herkomst | China |
|---|---|
Code geharmoniseerd systeem (HS) | 85176990 |
