Beschrijving
FULLY MODULAR DESIGNAll the black flat cables are modular design. Installing only the cables you need to reduce clutter, to increase the airflow and to improve the chassis thermal performance.HIGH QUALITY 100% JAPANESE CAPACITORSAll capacitors are high quality Japanese capacitors, to produce the efficient performance and to ensure the longer reliability.135MM SMART FANFan speed will be adjusted according to the system load. And the fan will stop when the system is idle or under low load (less than 20% load). The 2 ball bearing structure provides longer life time.80 PLUS GOLD CERTIFIED80 Plus Gold certified ensures to deliver 90% efficiency at 50% load. The better power efficiency leads to less power waste, less heat and less fan noise. And with the support of Intel processors, it will save more energy and more money.SINGLE +12V RAILSingle +12V rail provides the best power output, stability and compatibility for the hardware. It provides the easiest way to install the power cable. And it is the best design for overclocking.PROTECTIONIn order to make sure the entire computer system to operate stably under any conditions, we not only added protection designs such as OCP, OTP, OVP, OPP, UVP and SCP, but also ensured the stable operation of your system through the safety certification of various countries.
Productgegevens
| SKU | 1058745 |
|---|---|
| EAN | 4719331550912 |
| Fabrikantcode | GP-AP850GM |
| Merk | Gigabyte |
Specificaties
Energie
Totaal vermogen | 850 W |
|---|---|
AC-ingangsspanning | 100 - 240 V |
AC-ingangsfrequentie | 47 - 63 Hz |
Stroom | 10 A |
Power factor | 0,9 |
Power Factor Correctie (PFC) type | Actief |
Gecombineerd vermogen (+3.3V) | 120 W |
Gecombineerd vermogen (+12V) | 846 W |
Gecombineerd vermogen (+5V) | 120 W |
Gecombineerd vermogen(+5Vsb) | 15 W |
Max huidige output (+3.3V) | 20 A |
Max huidige output(+12V) | 70,5 A |
Max huidige output (+5V) | 20 A |
Max huidige output (-12V) | 0,3 A |
Max huidige output (+5Vsb) | 3 A |
Houd-tijd | 16 ms |
Efficientie | 90 procent |
Vertragingsbereik Power Good-signaal | 100 - 150 ms |
Stroomspanning bescherming | Overstroom, Te hoog vermogen, Overspanning, Oververhitting, Kortsluiting, Onder spanning |
Poorten & interfaces
Motherboard power connector | 20+4 pin ATX |
|---|---|
Lengte stroomkabel moederbord | 65 cm |
Aantal SATA power connectors | 6 |
Lengte SATA-stroomkabel | 450,550,650,750 mm |
Peripheral (Molex) power connectors (4-pin) | 6 |
EPS power connector (8-pin) | ✓ |
PCI Express power connectors (6+2 pin) | 6 |
CPU power connector (4+4 pin) | ✓ |
ATX power connector (20+4 pin) | ✓ |
Floppy drive power connector | 2 |
Aansluiting voor diskettestation | ✓ |
PCI Express connector | ✓ |
Bekabelingstype | Volledig modulair |
Prestatie
80 PLUS certificatie | 80 PLUS Gold |
|---|---|
Bedoeld voor | PC |
Vormfactor van de voeding (PSU) | ATX |
ATX version | 2.31 |
Mean time between failures (MTBF) | 100000 uur |
Design
Kleur van het product | Zwart |
|---|---|
Ventilator diameter | 13,5 cm |
Aantal ventilatoren | 1 ventilator(en) |
Ventilator locatie | Boven |
Aan/uitschakelaar | ✓ |
Gewicht en omvang
Breedte | 150 mm |
|---|---|
Diepte | 160 mm |
Hoogte | 86 mm |
Verpakking
Type verpakking | Doos |
|---|
Logistieke gegevens
Code geharmoniseerd systeem (HS) | 84733020 |
|---|
