Beschrijving
The SC-2702 27-inch surveillance monitor with BNC connector features 3-sided bezel-less specifically designed for security operators – especially those with a 24/7 operating multi-screen setup who are looking for efficient video monitoring. The SC-2702 provides value-added video enhancement controls that help create detailed images for low-light footage. Its optional monitor mounting solutions support single or multiple monitor setups. In terms of cost-to-performance, this model is the solution for productivity in modern operator workstations.3-SIDED BEZEL LESS MONITOR INCREASE PRODUCTIVITYThe SC-2702 adopts a seamless 3-sided bezel-less design to create a productive work environment and reduce gaps between monitors. Perform rapid analysis, manage, and control video sources from all locations. Evolving situations require quick decisions, which seamless monitors can help with.MULTIPLE MONITOR SETUPS MADE EASYWith VESA 100 x 100mm, the SC-2702 is compatible with AG Neovo’s mounting portfolio of desk and wall mounts. Whether you’re looking for a dual, quad, or more monitor set-up, AG Neovo is a one-stop-shop for creating ergonomic workstations in a control room.HIGHER COST PERFORMANCEDesigned with long-hour monitoring in mind, you can expect a reduction in system maintenance efforts and consequentially higher cost performance. The SC-2702 is commercial grade and meant to work 24/7, 365 days a year. Static images that would otherwise cause screen burn-in are gone with AG Neovo’s patented Anti-Burn-in technology. Expect prolonged life for LCD screens.PERFECT MATCH TO CCTV IMAGESThere is a special pre-configured CCTV Mode that maximises image clarity in low-light footage. Quickly fine-tune your video footage with adjustments for sharpness, saturation, contrast, brightness, and more. Don’t waste time testing and re-adjusting constantly, this product already has it all figured out!ENHANCED GAMMA SELECTIONOffering an enhanced gamma selection makes for amazing visual optimization. Improve the light, shadow, and colour balance quality of your videos with ease.MISSING DETAILS IN DARK SCENES IS A THING OF THE PASTMore detail from black-level adjustment means improved visibility of dark images.CONTRAST ENHANCERBy coming with a contrast enhancer, the surveillance monitor enables low-contrast images to become more clear and defined.ADAPTABLE TO SURVEILLANCE ENVIRONMENT NEEDSTailor the display to your needs with on/off toggles for the blue screen. When there is no signal available, a blue screen will show that is ideally designed for dark and low-light environments.VERSATILE CONNECTIVITY WITH BNC AND HDMI INPUTSThis 27-inch surveillance monitor with BNC Connector supports both analogue and digital video inputs. Easily connect to various video surveillance equipment with HDMI, VGA and BNC in/out ports. BNC port allows connecting CCTV cameras directly to the monitor. With this bezel less security monitor, there is no need for a DVR/converter to get straight to instant monitoring.
Productgegevens
| SKU | 1061762 |
|---|---|
| EAN | 4710739597325 |
| Fabrikantcode | SC-2702 |
| Merk | Neovo |
Specificaties
SC-2702
Beeldschermdiagonaal | 68,6 cm (27") |
|---|---|
Resolutie | 1920 x 1080 Pixels |
Oorspronkelijke beeldverhouding | 16:9 |
Touchscreen | ✕ |
HD type | Full HD |
Soort paneel | VA |
Responstijd | 5 ms |
Beeldscherm vorm | Flat |
Typische contrastverhouding | 20000000:1 |
Maximale refresh snelheid | 75 Hz |
Beeldscherm, aantal kleuren | 16.78 miljoen kleuren |
Helderheid (typisch) | 300 cd/m² |
Antireflectiescherm | ✓ |
Kijkhoek, horizontaal | 178° |
Kijkhoek, verticaal | 178° |
Pixel pitch | 0,311 x 0,311 mm |
Frequentiebereik horizontaal | 30 - 85 kHz |
Digitale verticale frequentie | 48 - 75 Hz |
Schermdiameter in centimeters | 69 cm |
Ingebouwde luidsprekers | ✓ |
Ingebouwde camera | ✕ |
Aantal luidsprekers | 2 |
Gemiddeld vermogen | 2 W |
Markt positionering | Industrieel |
Kleur van het product | Zwart |
HDMI | ✓ |
Hoofdtelefoon uit | ✓ |
VGA (D-Sub)poort(en) | 1 |
Aantal HDMI-poorten | 1 |
HDMI versie | 1.4 |
Ingang stroom | ✓ |
VESA-montage | ✓ |
Bevestigingsmogelijkheid voor kabelslot | ✓ |
Paneelmontage-interface | 100 x 100 mm |
Kabelslot sleuf type | Kensington |
kantel aanpassingen | ✓ |
Bereik kantelhoek | -5 - 20° |
Energie-efficiëntieklasse (SDR) | E |
Energie-efficiëntieklasse (HDR) | Niet beschikbaar |
Energieverbruik (SDR) per 1000 uur | 19,8 kWu |
Stroomverbruik (typisch) | 20 W |
Stroomverbruik (in standby) | 0,5 W |
Stroomverbruik (indien uit) | 0,2 W |
AC-ingangsspanning | 100 - 240 V |
AC-ingangsfrequentie | 50 - 60 Hz |
Soort voeding | Intern |
Energie-efficiëntieschaal | A tot G |
Bedrijfstemperatuur (T-T) | 5 - 35 °C |
Temperatuur bij opslag | -20 - 60 °C |
Relatieve vochtigheid in bedrijf (V-V) | 20 - 85 procent |
Luchtvochtigheid bij opslag | 10 - 90 procent |
Breedte apparaat (met standaard) | 613,8 mm |
Diepte apparaat (met standaard) | 226,5 mm |
Hoogte apparaat (met standaard) | 453,8 mm |
Gewicht (met standaard) | 4,5 kg |
Breedte ( zonder voet ) | 613,8 mm |
Diepte ( zonder voet ) | 47,4 mm |
Hoogte (zonder voet ) | 366,6 mm |
Gewicht (zonder voet) | 4,1 kg |
Breedte verpakking | 6780 mm |
Diepte verpakking | 134 mm |
Hoogte verpakking | 545 mm |
Gewicht verpakking | 6,1 kg |
Meegeleverde kabels | AC, Audio |
Snelstartgids | ✓ |
Certificering | CE LVD WEEE RoHS REACH UKCA EAC |
