Beschrijving
Shuttle Nano PC NC4010BAV2Intel Celeron 73058GB DDR4128GB M.21x HDMI1x DP7x USB1x LANinclVESA and standProcessorfamilie: Intel® Celeron®Processormodel: 7305Intern geheugen: 8 GBIntern geheugentype: DDR4-SDRAMKloksnelheid geheugen: 3200 MHzTotale opslagcapaciteit: 128 GBOpslagmedia: SSDOn-board graphics adapter model: Intel® UHD GraphicsInclusief besturingssysteem: Windows 11 ProArchitectuur besturingssysteem: 64-bitNetvoeding: 65 WType behuizing: Mini PCType product: Mini PCGewicht: 400 gKleur van het product: Zwart
Productgegevens
| SKU | 1066969 |
|---|---|
| EAN | 4046047104383 |
| Fabrikantcode | PFD-NC40U002 |
| Merk | Shuttle |
Specificaties
Processor
Processorfabrikant | Intel |
|---|---|
Processorfamilie | Intel® Celeron® |
Processormodel | 7305 |
Aantal processorkernen | 5 |
Processor aantal threads | 5 |
Prestatiekernen | 1 |
Efficiënte kernen | 4 |
Processor cache | 8 MB |
Processor cache type | Smart Cache |
Aantal geïnstalleerde processoren | 1 |
Processor basisvermogen | 15 W |
Maximaal turbovermogen | 55 W |
Geheugen
Intern geheugen | 8 GB |
|---|---|
Maximum intern geheugen | 64 GB |
Intern geheugentype | DDR4-SDRAM |
Geheugenslots | 2x SO-DIMM |
Kloksnelheid geheugen | 3200 MHz |
Non-ECC | ✓ |
Opslagmedia
Totale opslagcapaciteit | 128 GB |
|---|---|
Opslagmedia | SSD |
Soort optische drive | ✕ |
Aantal storage drives geïnstalleerd | 1 |
Totale capaciteit SSD's | 128 GB |
Aantal geïnstalleerde SSD's | 1 |
SSD capaciteit | 128 GB |
SSD interfaces | PCI Express |
NVMe | ✓ |
SSD-vormfactor | M.2 |
Grafisch
Aparte grafische adapter | ✕ |
|---|---|
Ingebouwde grafische adapter | ✓ |
Discreet grafische adapter model | Niet beschikbaar |
Interne-GPU-fabrikant | Intel |
Familie ingebouwde grafische adapter | Intel® UHD Graphics |
On-board graphics adapter model | Intel® UHD Graphics |
Prestatie
Markt positionering | Bedrijf |
|---|---|
Chipset moederbord | Intel SoC |
BIOS type | UEFI AMI |
Trusted Platform Module (TPM) | ✓ |
Type product | Mini PC |
Netwerk
Ethernet LAN | ✓ |
|---|---|
Ethernet LAN, data-overdrachtsnelheden | 10,100,1000 Mbit/s |
LAN controller | Intel® I219 |
Wifi | ✓ |
Wifi-standaard | Wi-Fi 6 (802.11ax) |
Wi-Fi-standaarden | Wi-Fi 6 (802.11ax) |
Fabrikant van de WLAN-controller | Intel |
WLAN-controller-model | Intel Wi-Fi 6 AX200 |
Soort antenne | 2x2 |
Bluetooth | ✓ |
Bluetooth-versie | 5.2 |
Poorten & interfaces
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A | 4 |
|---|---|
Aantal poortenUSB 3.2 Gen 1 (3.1 Gen 1) Type C | 1 |
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A | 2 |
Aantal DisplayPorts | 1 |
DisplayPort versie | 1.4a |
Aantal HDMI-poorten | 1 |
HDMI versie | 2.0b |
Aantal Ethernet LAN (RJ-45)-poorten | 1 |
Hoofdtelefoonuitgangen | 1 |
Microfoon, line-in ingang | ✓ |
Aansluiting voor netstroomadapter | ✓ |
Energie
Netvoeding | 65 W |
|---|---|
Voeding, voltage ingang | 100 - 240 V |
Ingangsfrequentie voeding | 50 - 60 Hz |
Design
Type behuizing | Mini PC |
|---|---|
Volume | 0,847 l |
Ondersteuning voor plaatsing | Horizontaal/Verticaal |
VESA-montage | ✓ |
Bevestigingsmogelijkheid voor kabelslot | ✓ |
Kabelslot sleuf type | Kensington |
Kleur van het product | Zwart |
Materiaal behuizing | Kunststof |
Software
Architectuur besturingssysteem | 64-bit |
|---|---|
Inclusief besturingssysteem | Windows 11 Pro |
Meegeleverde drivers | ✓ |
Beeldscherm
Inclusief monitor | ✕ |
|---|
Eisen aan de omgeving
Bedrijfstemperatuur (T-T) | 0 - 40 °C |
|---|---|
Relatieve vochtigheid in bedrijf (V-V) | 10 - 90 procent |
Gewicht en omvang
Breedte | 42 mm |
|---|---|
Diepte | 142 mm |
Hoogte | 142 mm |
Gewicht | 400 g |
Verpakking
Gewicht verpakking | 1,2 kg |
|---|
Inhoud van de verpakking
Meegeleverde kabels | AC |
|---|---|
Lengte stroomkabel | 1,7 m |
Inclusief VESA-montage | ✓ |
Inclusief schroeven | ✓ |
Certificaten
Certificaten van naleving | BSMI, CE, Federal Communications Commission (FCC), RoHS, UKCA, cTUVus |
|---|
Duurzaamheid
Naleving van duurzaamheid | ✓ |
|---|---|
Duurzaamheidscertificaten | ENERGY STAR, ErP |
Logistieke gegevens
Code geharmoniseerd systeem (HS) | 84714900 |
|---|
