Beschrijving
TP-Link Omada S7500-48XF4C. Switch type: Managed. Aantal USB 2.0-poorten: 3, Console port: RJ-45. MAC-adrestabel: 128000 entries, Switchingcapaciteit: 1760 Gbit/s. Rack-montage
Productgegevens
| SKU | TPL-S7500-48XF4C |
|---|---|
| EAN | 4895252505375 |
| Fabrikantcode | S7500-48XF4C |
| Merk | TP-Link |
Specificaties
Specificaties
Switch type | Managed |
|---|---|
Web-gebaseerd management | ✓ |
Cloud-beheerd | ✓ |
Type basis-switching RJ-45 Ethernet-poorten | ✕ |
Aantal moduleslots SPF+ | 48 |
Console port | RJ-45 |
Aantal QSFP28-poorten | 4 |
Aantal USB 2.0-poorten | 3 |
10G support | ✓ |
Datastroombeheer | ✓ |
Verbindingsaggregatie | ✓ |
Rate limiting | ✓ |
Spanning tree protocol | ✓ |
Ethernet LAN, data-overdrachtsnelheden | 1000,10000,40000,100000 Mbit/s |
VLAN=ondersteuning | ✓ |
MAC-adrestabel | 128000 entries |
Switchingcapaciteit | 1760 Gbit/s |
Verzending snelheid | 610,1 Mpps |
Jumbo Frames ondersteuning | ✓ |
Jumbo frames | 9000 |
Packet buffergeheugen | 8 MB |
DHCP-functies | DHCP client |
Multicast-ondersteuning | ✓ |
Beheerprotocollen | SNMPv1/v2c/v3 |
Rack-montage | ✓ |
Stapelbaar | ✓ |
Stroombron | AC |
Vermogenstoevoer inclusief | ✓ |
AC-ingangsspanning | 110 V |
AC-ingangsfrequentie | 60 Hz |
Vermogensverbruik (max) | 86,7 W |
Power over Ethernet (PoE) | ✕ |
Bedrijfstemperatuur (T-T) | -5 - 40 °C |
Temperatuur bij opslag | -40 - 70 °C |
Relatieve vochtigheid in bedrijf (V-V) | 10 - 90 procent |
Luchtvochtigheid bij opslag | 5 - 90 procent |
Warmtedissipatie | 295,85 BTU/h |
Breedte | 440 mm |
Diepte | 380 mm |
Hoogte | 44 mm |
Meegeleverde kabels | AC, LAN (RJ-45) |
Type verpakking | Doos |
